Titanium In CNC Machining
Titanium is a lightweight, strong material, 40% lighter than steel, making it ideal for high-tech industries like aerospace, automotive, medical, and energy. Available in pure and alloyed forms, titanium offers excellent corrosion resistance, biocompatibility, and strength-to-weight ratio, making it perfect for demanding applications in medical, aerospace, and chemical industries.
 |
 |
Description & Characteristics
| Price | $ $ $ $ $ | |
| Lead Time | < 10 days | |
| Wall Thickness | 0.75 mm | |
| Tolerances | ±0.125mm (±0.005″) | |
| Max Part Size | 200 x 80 x 100 cm | |
| Available Titanium |
|
|
| Applications | Titanium offers an excellent strength-to-weight ratio, high corrosion resistance, and biocompatibility, making it ideal for aerospace, automotive, and medical applications. It is also sterilizable and has low thermal expansion. | |
| Strengths | Titanium offers a high strength-to-weight ratio, excellent corrosion resistance, biocompatibility, durability, low thermal expansion, and non-magnetic properties, making it ideal for demanding applications. | |
| Weaknesses | High chemical reactivity, low thermal conductivity, and increased cutting forces can lead to surface oxidation, tool wear, machining challenges, and residual stresses, affecting overall machining efficiency and product quality. |
Parameters Of Aluminum
| Aluminum Alloy | Tensile Strength, Yield (MPa) | Fatigue Strength (MPa) | Elongation at Break (%) | Hardness (Brinell) | Density (g/cm³) |
|---|---|---|---|---|---|
| TA1 | 170-275 | 240 | 20-30 | 120-160 | 8.47 |
| TA2 | 275-380 | 240-260 | 20-28 | 160-200 | 4.51 |
| TC4/Ti-6Al 4V | 830-900 | 510 | 10-15 | 330-340 | 4.43 |
